Request for Quote

Specification Lite Pro
Stroke1 800 mm
31.5 in		 800 mm
31.5 in
Dead Length1 1340 mm
52.75 in		 1340 mm
52.75 in
Max Load 20 kN
4500 lbf		 20 kN
4500 lbf
Max Speed 150 mm/s
6 in/s		 2000 mm/s
78 in/s
Voltage 48 V 48 V
Max Current 35 A 220 A
System Width 302 mm
12 in		 320 mm
12.6 in
System Depth 110 mm
4.3 in		 161 mm
6.3 in
Load Sensing ✔ ✔
Position Sensing ✔ ✔
Motor Brake ✔ —
Failsafe Brake — ✔
Shock Absorption — ✔

1 Standard length. Length and end configurations can be customized during the ordering process.

Development Kit includes:

  • 48V Battery and charger
  • UI Tablet and selected CPU
  • Interface cables
  • 8 hours of engineering support
